J7208 Smart AI Thick Film Screen Printer
High performance sensors, chip elements, thick film circuit(automotive , military , aerospace , medical applications) chip resistance and capacitance, LTCC, HTCC,HIC, RFID (radio frequency identification system) circuit/antenna, high-power LED and other fields.
Ø Redefine key variables and standards for high-end printing
Ø Dynamic data will change the perception of the printing process
......
J1202-RS Thick Film Screen Printing
Thick film circuit, pressure sensor (piezoresistive, capacitive), glass glaze potentiometer, dielectric antenna, ceramic metallization, microwave magnetron, RFID, automotive oil level sensor, air quality sensor, integrated LED lamp holder, tension sensor, piezoelectric ceramic components, etc
Ø Full motor operation, no vacuum source is required, no air source is required, and it can be run in the case of mains power
Ø Squeegee control system obtained invention patent :ZL2012105631167, valid for 20 years
......
J3202 Fully Automatic Thick Film Screen Printer
Thick film circuit, pressure sensor (piezoresistive, capacitive), glass glaze potentiometer, dielectric antenna, ceramic metallization RFID, automotive oil level sensor, LED ceramic bracket, tension sensor, piezoelectric ceramic components, etc.
Ø Design adopts modular combination, can be single-machine semi-automatic or online automatic operation
Ø Suitable for automatic printing of multi-specification porcelain chips, and can quickly change the tooling to achieve product conversion
......
High precision thick film screen printers J3201
Thick film circuit, pressure sensor (Piezoresistive , Capacitive), RF device, ceramic metallizationRFID, piezoelectric ceramic components, etc. Most suitable for automatic printing of small and shaped work pieces.
Ø Design adopts modular combination, can be single-machine semi-automatic or online automatic operation
Ø Suitable for automatic printing of multi-specification porcelain chips, and can quickly change the tooling to achieve product conversion
......
Thick Film Screen Stencil Printer J5206CX-RS
Realize standard thick film printing system, ceramic metallization printing, through hole metallization printing, flexible plate printing such as PET (with micro-hole vacuum printing platform), and solder paste printing of PCB.
Ø Automatic screen cleaning function
Ø Lighting system:screen lighting, printing table lighting and backlight to check printing effect
......
J3202B Fully Automatic thick film screen printing equipment
Thick film circuit, suitable for thick film printing of heavy workpieces
Ø Design adopts modular combination, can be single-machine semi-automatic or online automatic operation
Ø Suitable for automatic printing of multi-specification porcelain chips, and can quickly change the tooling to achieve product conversion
......
Thick film screen printing machine from Weizhi Electronics offer high-precision solutions for various industries, including sensors and chip elements. With advanced features and customizable options, these machines ensure reliable, efficient, and automated printing.
